Microphone LCD Lift Conference System
Guangzhou Long Gui Technology Co., Limited- Style：Modern
- Material：Metal
- Wood Style：Solid Wood
- Folded：Unfolded
- Customized：Customized
- Condition：New
Base Info
- Model NO.：LGT-21A
- Ultral Slim：Full HD and Nice Design
- Transport Package：Carton
- Specification：Aluminium and cold rolled steel
- Trademark：LGT
- Origin：China
- HS Code：8529909090
- Production Capacity：500 Piece Per Month
Description
| Transmission type capacitive screen supports 10 points touch |
| Using Taiwan EXC3000 control chip |
| Stable and reliable touch sensitive |
| computerconnection mode USB or RS232 |
| The touch screen's transmittanceis more than 90% |
| Surface hardness 5H,structure GG,driving mode COB |
| Reaction time is less than 10MS |
| Read speed 10 PT 80HZ |
| Anti static,contact point 4kv |
| Maximum operating frequency 100MHZ |
| Touch life is more than 300000000 times |
| Operating temperature -30 degrees to 75 degrees |
| Humidity 90% at 60 degrees |
Ultra Thin High Definition Touch Display Screen With PC
| Onboard i7-2630M Intel dual core 1.7G CPU,hudson M1 AMD chipset |
| DDR3 memory 4G 32G solid state hard disk 4*RS232 serial port |
| COM4 Support RS485/422 mode USB*6 |
LCD Lift Details
| Power Support:AC220 / 12A 50Hz |
| power consumption:10VA/ units excluding power consumption display |
| lifting time:45s |
| loading capacity:the maimum is 3.5kgs |
| whole weight :15 kgs(including monitor) |
| lifting accuaracy:the level |
| of positive and negative 0.2mm |
| vertial plus or mius 0.2mm |
| Environmental conditions:Temperature 5 degrees to 45 degrees |
| Panel size:488L*88W*5T mm |
| flip door size:401L*34W mm |
| Box size:476L*75W*605H mm |
| cutting size:479L*78W mm |
