• Model NO.：65 mm collapsing sliding partition
• Type：Office Furniture
• General Use：Commercial Furniture
• Product Name：Soundproof Partition Walls
• MOQ：No MOQ
• Feature：Space Saving
• Packing：Plywood Crate
• Application：Hotel and Office
• Production Time：Normal 15 Days
• Warranty：3 Years
• Transport Package：Standard Wood Case
• Specification：65 mm thickness
• Trademark：EBUNGE
• Origin：Guangzhou, China
• HS Code：94031000
• Production Capacity：50000 Square Meters Per Month

SeriesBG65BG85BG100Panel suspensionTop hung onlyTop hung onlyTop hung onlyTrack systemSingle or twin pointSingle or twin pointSingle or twin pointPanel thickness65mm80mm / 85mm100mmPanel heightUp to 4000mmUp to 6000mmUp to 18000mmMax height4000mm6000mm18000mmPanel width600-1230mm600-1230mm600-1230mmFrame constructionAluminum frameAluminum frameAluminum frameFace material9mm9mm / 12mm12mmFire safetyOptional Class I or OOptional Class I or OOptional Class I or OVertical profilesAluminum anodised with sealing profilesAluminum anodised with sealing profilesAluminum anodised with sealing profilesRetractable sealsAluminum black with
double rubber sealsAluminum black with double rubber sealsAluminum black with double rubber sealsOperation of sealsManual, with supplied
operating handleManual, with supplied operating handleManual, with supplied operating handleLockingOptional lock to pass doorsOptional lock to pass doorsOptional lock to pass doorsPass doorsSingle open in panel or double open in two panelSingle open in panel or double open in two panelSingle open in panel or double open in two panelSound insulation20-32dB Rw28-36dB Rw32-50dB RwWeightApprox 22-35kg/sq MApprox 25-40kg/sq MApprox30-48kg/sq MFinish MaterialPlywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting,etc. (Customized)
3. Advantage

1. BUNGE movable walls are a hugely popular solution for spaces that need to be quickly subdivided or opened up according to the user's changing needs. With three different ranges available in a multitude of finishes, creating the ideal system for your space is simple.

2. Our outstanding range of acoustic movable partitioning walls offers superb sound reduction properties and effortless maneuverability. The lightweight sliding panels have been expertly designed to allow users to quickly and effectively optimize space by stacking neatly at the side of a room to open it up or alternatively sliding along a top track to create multiple separate areas.

3.Private 3 years warranty and free install videos.



4.Package

BUNGE Movable Partition Wall standard packing used carton paper for Full container loading, if only LC Loading, will use wooden box for the panels packing.
Packing details is Carton package, MDF batten on four section sides, foam board on both front faces. For special surfaces, like glass partition wall we can get wooden boxes packing for you.
Sea transport is a common mode of transportation. In an emergency, can be air freight.



5.FAQ

1): What should you do on-site?

A beam (truss)should be built on-site for track installation. The minimum distance leaving for track installation from a false ceiling to the top ceiling is 180mm.

2): How to install?

We will provide the installation manual and video guiding the installation job. We can also dispatch the installation engineer supervising the installation as request.

3): What is the finishing surface?

The bottom panel is MDF or plywood, which is an unfinished face.

You can do decoration on-site, such as wallpaper, paint, etc,

We can also provide the product with a finished face, such as melamine, faux wood, woven fabric, and leather.

Choose from our stylish fabric or leather covers and have the option to have a soft/ hard surface.

We can also provide a glass partition for glass clips or aluminum frame panels.
