• Model NO.：65 mm collapsing folding partition
• Customized：Customized
• Material：Wood
• Condition：New
• Product Name：Soundproof Movable Partition
• Application：Movable Partition Wall
• High：Less for 4m
• Sample：Customzied
• Warranty：3-5years
• Main Material：MDF+Aluminum
• Surface Color：Customzied
• Panel Thickness：9mm
• Max High：4m
• Transport：Depends on Client
• Transport Package：Carton Package, MDF Batten on Four Section Sides,
• Specification：65 mm thickness
• Trademark：EBUNGE
• Origin：Guangzhou, China
• HS Code：94031000
• Production Capacity：50000 Square Meters Per Month
• Package size per unit product：250.00cm * 130.00cm * 8.00cm
• Gross weight per unit product：30.000kg

Series

BG65

BG85

BG100

Panel suspension

Top hung only

Top hung only

Top hung only

Track system

Single or twin point

Single or twin point

Single or twin point

Panel thickness

65mm

80mm / 85mm

100mm

Panel height

Up to 4000mm

Up to 6000mm

Up to 18000mm

Max height

4000mm

6000mm

18000mm

Panel width

600-1230mm

600-1230mm

600-1230mm

Frame construction

Aluminum frame

Aluminum frame

Aluminum frame

Face material

9mm

9mm / 12mm

12mm

Fire safety

Optional Class I or O

Optional Class I or O

Optional Class I or O

Vertical profiles

Aluminum anodised with sealing profiles

Aluminum anodised with sealing profiles

Aluminum anodised with sealing profiles

Retractable seals

Aluminum black with
double rubber seals

Aluminum black with double rubber seals

Aluminum black with double rubber seals

Operation of seals

Manual, with supplied
operating handle

Manual, with supplied operating handle

Manual, with supplied operating handle

Locking

Optional lock to pass doors

Optional lock to pass doors

Optional lock to pass doors

Pass doors

Single open in panel or
double open in two panel

Single open in panel or double open in two panel

Single open in panel or double open in two panel

Sound insulation

20-32dB Rw

28-36dB Rw

32-50dB Rw

Weight

Approx 22-35kg/sq M

Approx 25-40kg/sq M

Approx30-48kg/sq M

Finish Material

Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.  (Customized)

Free Sample in 10 Days

Inquiry now and you will have your sample in 10 day if you pay the express.

3-year Warranty

The acoustic room divider made of  6063-T5 alumina, anti-aging, no fading and abrasion in 10 years

OEM Service

Your logo can be printed on the packaging carton

We Offer:

(1).A full professional partition wall design service.

(2).Survey and installation surpervise.

(3).Using top quality materials and components for the partition wall.

(4).A fully experienced partition wall work team.

(5).Maintenance contracts to ensure your valuable asset remains in full work order.
